Section 855.APPENDIX B   Illustrations – Inspection and Management Plan Forms



Section 855.ILLUSTRATION D   Sampling Area Diagram (Boiler Room)



Description of Boiler Room                Sampling Area I.D.# A,B,C

Construction 1957

Damaged friable pipe and boiler insulation

Grayish-white chalky material



Each should be a separate diagram and sampling area



Sample Area "A" - Pipe Insulation

Sample Area "B" - Pipe Joints

Sample Area "C" - Boiler Insulation



Note:  Do not sample the above as one sample area

School I.D.#



School Name



Address



Phone Number



Inspector Name & I.D.#



Date of Inspection



Diagram Prepared by



Date
